CHM Paper Rotary Sheeter Machine--Automatic Web Guide System
Automatic web guide system is usually used in the following situations:
1. When the roll paper is prone to deviation or deviation during transportation.
If the paper is not accurately aligned with the cutting position, it may cause uneven cutting, waste of materials and affect product quality. At this time, the automatic edge guide system can adjust the paper position in time to ensure that it is transported along the correct path.
2. In high-speed cutting operations.
Due to the high speed, the paper is more likely to deviate. The automatic edge guide system can monitor in real time and quickly correct it to ensure the accuracy and stability of cutting.
3. For production tasks with high slitting accuracy requirements.
Even a small deviation may affect the quality and specifications of the final product. The automatic edge guide system helps to maintain the precise position of the paper.
4. When handling thinner or softer paper.
This type of paper is more susceptible to deviation due to factors such as airflow and mechanical vibration. The automatic edge guide system can effectively solve this problem.
5. When the roll paper slitting machine is running continuously for a long time.
In order to reduce the workload of manual monitoring and adjustment and improve production efficiency, the automatic edge guide system can play a role continuously and stably.
The working principle of the automatic edge guiding system is usually realized through a series of sensors, controllers and actuators.
The common working principle is as follows:
The system will be equipped with photoelectric sensors or other types of detection devices to monitor the edge position of the roll paper in real time. When the paper deviates during transportation, the sensor can detect the deviation between the edge of the paper and the set reference position.
The sensor transmits the detected deviation signal to the controller, and the controller sends the corresponding instructions to the actuator after analysis and processing. The actuator may be an electric push rod, a cylinder, a servo motor, etc., which will adjust the position of the paper according to the instructions.
For example, the actuator can push or pull the unwinding device, guide roller or other related components of the roll paper to return the position of the paper to the correct track, thereby realizing the function of automatic edge guiding.
In this way, the automatic edge guiding system can correct the deviation of the paper in real time, ensure that the paper maintains the correct position during slitting or other processing, improve cutting accuracy and product quality, and reduce material waste. The automatic edge guiding systems of different models and manufacturers may differ in specific structure and working methods, but the overall principle is to realize the edge guiding function by detecting deviations and making automatic adjustments.
Advantages of the automatic edge guide system:
- Improve slitting accuracy: It can monitor and correct the deviation of the roll paper during the conveying process in real time, ensure that the paper moves along the correct path, thereby improving the accuracy of slitting and reducing the scrap rate.
- Improve product quality: Make the edges of the slitting paper more neat and the size more accurate, which helps to improve the quality of the final product.
- Increase production stability: When producing at high speed or processing thinner and softer paper, it can effectively avoid paper deviation and ensure the stability of the production process.
- Reduce the need for manual intervention: Reduce the reliance on manual real-time monitoring and adjustment of paper position, saving labor costs.
- Adapt to a variety of working conditions: It can be adjusted according to different paper types, production speeds and other working conditions, and has strong adaptability.
