A Reliable Single Rotary Sheeter for Modern Paper Converting

In today's paper converting industry, efficiency, cutting accuracy, and production stability are essential for maintaining competitiveness. Whether serving paper mills, printing companies, packaging manufacturers, or paper merchants, a reliable Paper Sheeter Machine plays a critical role in converting paper rolls into high-quality sheets.

Developed by CHM Machinery, the CHM-1700 Paper Sheeter is a high-speed Single Rotary Sheeter designed to deliver accurate and efficient roll-to-sheet production. Combining proven cutting technology with automated control systems, the CHM-1700 has become a popular choice for converters worldwide.

What Is the CHM-1700 Paper Sheeter?

The CHM-1700 is a precision Roll to Sheet Cutting Machine that integrates unwinding, slitting, cutting, conveying, counting, and stacking into a continuous production process.

Designed for a wide range of paper grades, the machine can process paper weights from 60gsm to 550gsm. It is widely used for commercial printing paper, office paper, packaging paper, kraft paper, and specialty paper applications.

As a professional CHM Paper Sheeter, the machine provides an ideal balance between productivity, operating stability, and investment cost.

How Does the CHM-1700 Work?

Production begins with hydraulic reel loading on the unwind stand. An automatic tension control system continuously adjusts web tension according to paper weight and reel diameter, ensuring smooth paper feeding throughout the production cycle.

The paper then passes through the slitting section where edge trimming can be performed when required. After that, the web enters the high-precision cutting unit.

The CHM-1700 uses a top rotary knife and fixed bottom knife configuration. This Single Rotary Sheeter design reduces vibration while maintaining stable sheet length accuracy and clean cutting performance.

After cutting, the sheets are conveyed through an anti-static transport system before entering automatic counting, jogging, and stacking sections for efficient collection.

Technical Highlights

The CHM 1700 Sheeter supports a maximum reel diameter of 1800 mm and a maximum sheet width of 1700 mm. Sheet lengths can be produced from 450 mm to 1650 mm.

Production speed reaches up to 300 cuts per minute and 300 meters per minute, making the machine suitable for high-volume production environments.

Cutting accuracy is maintained at ±0.5 mm for sheet lengths below 1000 mm and ±0.1% for longer sheets, providing reliable performance for demanding printing and packaging applications.

The machine is capable of processing up to two rolls simultaneously, improving productivity while maintaining stable sheet quality.

Suitable Paper Grades

One of the major strengths of the CHM-1700 is its versatility.

The machine is highly suitable for woodfree paper, copy paper, writing paper, offset paper, and other uncoated printing grades. It also performs well when processing kraft paper, coated paper, corrugated medium paper, duplex board, and white top liner.

For most converters, the optimal operating range is between 60gsm and 250gsm. Within this range, the machine delivers excellent productivity, stable paper handling, and high cutting quality.

For heavier materials from 250gsm to 550gsm, the CHM-1700 can still provide reliable performance when configured appropriately and operated within recommended production parameters.

Why Choose the CHM-1700?

Several features contribute to the machine's performance. Automatic tension control maintains stable web feeding, while the EPC web guiding system continuously corrects paper alignment. Anti-static devices improve sheet separation and stacking quality during high-speed production.

Automatic counting and label insertion functions reduce manual labor and improve production management efficiency. Combined with a robust mechanical structure, precision rotary cutting system, and reliable drive technology, these features help maximize uptime and reduce waste.

As one of the most widely used models from CHM Machinery, the CHM-1700 offers an excellent balance between production capacity, sheet quality, and operational reliability.

Conclusion

The CHM-1700 Paper Sheeter is a proven Single Rotary Sheeter designed for efficient roll-to-sheet production. With speeds up to 300 m/min, precision cutting accuracy, and compatibility with paper grades ranging from 60gsm to 550gsm, it remains a dependable solution for paper converters worldwide.

For businesses seeking a high-performance Paper Sheeting Machine that combines productivity, accuracy, and long-term reliability, the CHM-1700 continues to be one of the most trusted models offered by CHM Machinery for printing paper, packaging paper, and industrial paper converting applications.
