Automatic Paper Sheeter Machine
This single blade 1700 slitting machine from Changjiang Machinery can achieve high-speed slitting of multiple rolls at the same time, with strong performance. It adopts advanced technology AC servo motor drive, with fast and stable paper cutting speed.
Product Introduction
This single blade 1700 slitting machine from Changjiang Machinery can achieve high-speed slitting of multiple rolls at the same time, with strong performance. It adopts advanced technology AC servo motor drive, with fast and stable paper cutting speed. It is currently a paper processing machine commonly used in paper factories and printing factories. It is suitable for slitting various types of paper, and the slitting products are neat.
youtube
Product Parameter
|
Model |
CHM-1700 |
|
1. Type of cutting |
Top blade rotary, bottom blade fixed |
|
2. weight of paper |
60-550 GSM |
|
3..reel diameter |
Max 1800mm (71") |
|
4. Finished width |
Max 1700mm (66.9") |
|
5. Finished sheet-Length |
Min.450-Max.1650 mm |
|
6. Num.of rolls cutting |
2 rolls |
|
7. Cutting accuracy |
±0.5mm(L<1000mm) ±0.1% (L≥1000mm) |
|
8. Max.speed of cutting |
300cuts/min |
|
9. Max.cutting speed |
300m/min |
|
10. Requirement of the air pressure |
0.8MPa |
|
11. Voltage |
AC380V/220Vx50Hz |
|
12. Total power: |
27KW |
|
13. Accuracy of the roller paper sheet |
±0.5mm(L<1000mm);±0.1% (L≥1000mm) ±0.1%(accelerate or decelerate). This depend on machine stable and operation when cutting. (cutting one paper roll, the cutting length is right ) |
|
14. Output |
The real output depend on the material, and the weight of the paper, and right operate process |
Product details
Shipment picture:
FAQ
1.What are the features and advantages of this machine?
It is equipped with multiple functions,real time digital control,production record function,no paper rollers equipment.
2.What types of paper can this machine cut?
Board paper,art paper,kraft paper,offset paper and etc.
3.How to solve the problem of static electricity generated during the slitting process?
Our machine is equipped with a static elimination system, which can eliminate the static electricity generated during slitting.
